Sterling Fans Commercial Series SEPD 300 SC Bathroom Fan
Sterling Fans Commercial Series SEPD 300 SC Bathroom Fan
Use code thankyou10 at checkout and save 10% off your entire order. All orders Ship Free!
In stock
Couldn't load pickup availability
Introducing the SterlingFans SEPD 300 Commercial Bathroom Fan: the little brother to the SED 400 and 500 series that is smaller in size but still offers up a satisfying 290 CFM to clear out humidity and odours in offices, restaurants and schools, etc.
Designed for an 6" duct and featuring a high-quality DC motor, it's designed to operate continuously, and features a lightweight backdraft damper. Running on 120V/60 Hz and consuming just 52 watts, it's a fantastic choice for mid sized commercial bathroom applications.
And with built-in overload protection, it's built to last in even the busiest commercial settings. For reliable, high-performance ventilation, the SterlingFans SEPD 300 is a great choice.
All SterlingFans Commercial series fans meet Codes and standards including ASHRAE 62.2, LEED, Performance is ENERGY STAR qualified, JA8 Title 24, CalGreen and WA Ventilation code. Why purchase a DC motor powered Bathroom Fan? Read our blog.
Features:
- Rust resistant paintable metal housing
- Designed for an 6" duct
- Housing Size - 11 3/8" x 10.5" x 7 5/8"
- Grille Dimensions 13" x 14"
- DC Motor - (4.0 sones)
- Permanently lubricated Motor rated for continuous operation
- Certified by ETL in accordance with UL and CSA standards
- Tested by high quality ISO 17025 Standard Government accredited laboratories
- Performance is ENERGY STAR qualified
- Selectable output from 50CFM to maximum
- Low profile polymeric resin Grille (paintable)
- 290 CFM @0.1 w.g - 120v/60Hz
- Power consumption 52W
- 2 Year warranty
Share
Commercial SED Series Specifications
Model | SED 400 | SED 500 | SEPD 300 |
CFM (static press 0.1 w.g.) | 400 | 500 | 290 |
Noise (sones) | 3.0 | 4.0 | 4.0 |
Energy usage | 40W | 59W | 52W |
Duct Diameter | 8 inches | 6 inches | |
Power Rating | 120v/60Hz | ||
Housing Size | 14 1/4" x 14 1/4" x 9" | 11 3/8" x 10.5" x 7 5/8" | |
Grille Dimensions | 17 1/4" x 17 3/4" | 13" x 14" | |
Motor | DC | ||
Selectable CFM toggle | 100 CFM to Max | 50 CFM to Max |
